| 2110 |
|
- 분류 : 계측센서 > 토크/RPM 센서
- 제조사 : Honeywell
- 정밀도 : 0.1%
- 허용과부하 : 150%
- 정격출력 : 0~100mV
|
|
|
Range2,000 lb-in, 5,000 lb-in
10,000 lb-in, 20,000 lb-in, 30,000 lb-in
50,000 lb-in, 100,000 lb-in
200,000 lb-in
300,000 lb-in, 500,000 lb-in
600,000 lb-in, 750,000 lb-in
1,200,000 lb-in, 2,400,000 lb-in
Non-Linearity±0.1 % rated output
Hysteresis±0.1 % rated output
Repeatability±0.05 % rated output
Temperature, Operating-54 °C to 93 °C [-65 °F to 200 °F]
Temperature, Compensated21 °C to 77 °C [70 °F to 170 °F]
Temperature Effect, Zero±0.002 % of rated output/°F
Temperature Effect, Output±0.002 % of reading/°F
Electrical TerminationMS-3102E-14S-5P
Torsional StiffnessFrom: 2,000 lb-in = 43,384 lb-in/rad
Up to: 2.4M lb-in = 48.6X10^6 lb-in/rad |
